Art No.

JSGC-420C

JSGC-960C

JSGC-1500C

Chamber Volume (Capacity)

432 L

972 L

1512 L

Dimensions

Inner

600 x 600 x 1200

900 x 900 x 1200

1400 x 900 x 1200

W x D x H mm

Outer

1180 x 850 x 2080

1480 x 1150 x 2080

1980 x 1150 x 2080

Temperature

Range

Light Off : +0 oC ~ 60 oC   Light On :+10 oC ~ 60 oC w/o Humidification



Accuracy

± 0.3 oC at 20.0 oC, 60% RH (Light Off)



Uniformity

± 1.0 oC at 20.0 oC, 60% RH (Light Off)

Humidity

Range

30 ~ 98% RH (Sensor Range)   30 ~ 85% RH (Control Range)



Accuracy

± 3.0 % RH at 20.0 oC 60% RH



Uniformity

± 6.0 % RH at 20.0 oC 60% RH

Illumination

Range

0 ~ 40,000 Lux



Steps

6 Step Combination

7 Step Combination

8 Step Combination



Lamp

2 x 150 Watt HQI Lamps

3 x 150 Watt HQI Lamps

4 x 150 Watt HQI Lamps



Configuration

4 x 55 Watt FPL

4 x 55 Watt FPL

8 x 55 Watt FPL

CO2 Control

Conc. Range

ambient ~ 5,000 ppm (ambient ~ 20 %)



Accuracy

± 50 ppm

Controller

Programmable PID Control 11 segments 999 cycle repeatable

Sensors

Temp

Class A Pt-100 ? Sensor



Humidity

Electronic Humidity Sensor



CO2

High Precision Dual Wavelength NDIR Diffusion Sensor



Light

Lux Meter

Number of shelves / Max. No.

3 / 37

4 / 37

8 / 43

Heater Capacity

4.0 kW

6.0 kW

8.0 kW

Refrigeration System

CFC-Free Air Cooled Hermetically Sealed Compressor

Electric Requirement

220VAC 50/60Hz 1P

Power Rating

30 Amp

36 Amp

53 Amp

Power Plug

30 AMP

50 AMP

Direct to 60 Amp







ELB Mains
